Introducing ADDAC701 Voltage Controlled Oscillator
12HP Eurorack format
more here->
-
Introducing ADDAC503 Marble Physics
10HP Eurorack format
more here->
-
Also updated ADDAC200 Multiples, ADDAC502B and ADDAC205B
Autumn Updates*
Introducing ADDAC102 VC FM Digital Radio!
8HP Eurorack format
compatible with +-12v and +-15v power supplies
more here->
-
Regarding ADDAC System front panel colors.
Due to requests and feedback new ADDAC System Modules will now be produced in candy RED
Gold, black, green, blue, grey and white panels are now available as custom orders.
Here’s a picture of a recent custom black order
-
&&& and &&&
Here’s a video preview on some recent + future modules:
ADDAC001 VCC – Voltage Controlled Computer
ADDAC002 VCC – CV Inputs
ADDAC004 VCC – Digital Inputs
ADDAC005 VCC – Digital Outputs
ADDAC204 VC CV Mapping
ADDAC205 Dual Oscilloscope
-
It’s also a pleasure to announce that Rhythm Active is now the Official Australia Distributor.
Posted in Uncategorized Leave a comment
Available: ADDAC001 Voltage Controlled Computer & ADDAC901 3U FRAME
Re-inventing the first Arduino based Analog-to-Digital-to-Analog Modular USB Interface
See it Live at NIME 2011, New Interfaces for Musical Expression Conference in Oslo, May 30th – June 1st
ADDAC001 VS3
Voltage Controlled Computer
8 Channel Digital to Analog Converter AD5668 IC with:
.16 bits resolution (0-65535)
.bipolar -5+5v or positive 0+5v output
.2 monitor leds per channel
2 x 16 position switch
Reset Button
MiniB USB connection
Arduino based Software with ATMEGA1280 IC
Transmit & Receive Leds
USB programmable
12HP
Eurorack format
compatible with +-12v and +-15v power supplies
I’ve been developing this idea for the last 2 years, this is VS3 – better than ever!
-
&&& and &&&
-
ADDAC901 – 3U Frame
Standard Eurorack style 3U Frame
Available either assembled or diy
Rails included
optional:
ADDAC900 Bus Board
ADDAC902 ±12v Power Supply 1.2A
Posted in Uncategorized Leave a comment
ADDAC101 .WAV Player 100th Unit Commemorative Edition!
It’s up for Auction the commemorative 100th Unit of ADDAC101 .WAV Player
It’s available worldwide, please visit the Auction here:
http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=140536932546#ht_614wt_1141
ADDAC801 SIMPLE MIXER is also Available!
Posted in Uncategorized Leave a comment
NIME 2011
I was selected to be at the 2011 New Interfaces for Musical Expression Conference in Oslo (May 30th to June 1st) presenting a Poster titled “Towards a Voltage-Controlled Computer – Control and Interaction Beyond an Embedded System” this shares some of my research in the ADDAC00X series, which pretends to be a platform for simple interaction among digital and analog worlds.
for more info about the NIME Conference please visit:
http://www.nime2011.org
Posted in Uncategorized Leave a comment
March* Updates!
Introducing ADDAC901 3U Wood Frame Series!
ADDAC901 3U Wood Frame
ADDAC901F 3U Flat Wood Frame
ADDAC901A 3U Angled Wood Frame
These will be available as finished cases or as DIY kits.
Rails will be included
Pre-orders Available!
Shipping soon!
also available:
ADDAC900 Bus Board
And started Shipping:
ADDAC203 CV Mapping
ADDAC501 Complex Random
ADDAC501B Complex Random Expansion
ADDAC802 VC Mixer
More soon*
Posted in Uncategorized Leave a comment
ADDAC System Java Simulators
Following my last post i decided to code Java Simulators to simulate some of the most complex CV generators i offer, with the idea of always addressing the same question:
What do they do exactly??
So these Java Simulators will behave the closest possible to the real thing.
Simulators have audio output, the simulated CV output controls a sine wave frequency as if a VCO was connected to the module output.
And so, here’s another one:
ADDAC203 CV Mapping Simulator
Download v1.0
OSX application
Linux Application
Windows Application
ADDAC501 Complex Random Simulator
Download v1.2
OSX application
Linux Application
Windows Application
You can also try them in a browser but i promise it’ll be slow:
http://addacsystem.org/ADDACjava/addac203
http://addacsystem.org/ADDACjava/addac501
ADDAC Java Simulators built with Processing
Posted in Uncategorized Leave a comment
ADDAC501 – The Missing Explanation!
I’ve been announcing the ADDAC501 Complex Random and it’s side companion ADDAC501B Complex Random Expansion
But what do they do exactly??
Like the name suggests, it’s complex to describe by words…
So i thought of making a small java application that could run on a browser, i made it and behaves exactly like the ADDAC501, but unfortunately browsers don’t seem fast enough for it to run smoothly, so there’s downloadable versions for 3 platforms bellow.
Download v1.2*
(already uploaded an updated version with simulated sound output):
OSX application
Linux Application
Windows Application
You can also try it in a browser but it’ll be slow:
http://addacsystem.org/ADDACjava/addac501
Built with Processing
Posted in Uncategorized Leave a comment
Welcoming 2011 first Modules!
Happy New Year!
i’ve been talking about this modules for a while now, so here they are:
ADDAC203 CV MAPPING (in Stock!)
2 independent channels with Attenuator & Offset controls
ADDAC501 Complex Random (now with clock gate input) **
Complex Random with Brownian function
ADDAC501B Expansion
with Variable Glide function + Normal and Inverted Gate Outputs
ADDAC502 Lissajous Curves *
2 independent XY Lissajous Curves with MIN/MAX & Speed Controls
4 independent Outputs with 10 possible average combinations, ex:
X1
X1+X2
X2 + Y1 + Y2
X1 + X2 + Y1 + Y2 …
ADDAC502B Expansion
with Normal and Inverted Gate Outputs
ADDAC801 Simple Mixer
3 Channel Mixer
ADDAC802 CV Audio Mixer
with 5 VCA channels
and 1 VCA Mixdown Output
ADDAC900 Bus Board
2 Styles with IDC Boxed Headers or Pinout Header
ADDAC901 3U Frame
EuroRack 3U Poplar Frame
Pre-orders available!
*this are the prototype panels, as you might notice, some engravings are not final. Also, because i’m changing the jacks i’ve been using, the Complex Random and Lissajous Curves have some holes bigger than they should be.
All this will be corrected in the first batches!
Soon i’ll post more info and demo videos!
Posted in Uncategorized Leave a comment
Loading ...
The ADDAC701 Voltage Controlled Oscillator
We were recently thrilled to announce our new analog oscillator, the ADDAC701. For us this is an extremely important addition to our product line and a relevant step in completing a first stage of ADDAC’s offer in modular synths.
We are extremely proud with the performance of the ADDAC701 VCO, a fully analog oscillator inspired by the original Moog, and promising to deliver pristine quality.
You can now check it in action in our newest video. For more information jump right to the product page.
